Foul Weather Whip V2 Ham Antenna
Foul Weather Whip V2 Ham Antenna
Free US shipping on orders $35+ · Ships in about 2 weeks · Hand-built in San Diego · 30-day returns & lifetime warranty
Couldn't load pickup availability
Need an adapter? Most handhelds do.
Look at your radio's antenna port: a pin means SMA Female, a hole means SMA Male.
The Foul Weather Whip V2 for ham radio. A rugged, hand-built BNC whip that won't sag in the cold, thanks to a 1.6 mm NiTinol radiator. Sturdy strain-relief back shell and a bigger clasp-style BNC. Every antenna is hand made and tuned in-house in San Diego, California, using components from American small businesses.
Band options
- 2M/70cm Dual Band: tuned 146 & 430 MHz (±15 MHz). Also works on FRS/MURS/GMRS.
- 1.25M/70cm Dual Band (12.5 in): tuned 222 & 440 MHz, for tri-band radios. Typical SWR about 1.5:1 at 222 MHz and 2:1 at 440 MHz.
- UHF Monoband 7 in: tuned 435 MHz (±15 MHz).
We recommend a dual band over the monoband: higher gain, better reception and clearer comms. Every antenna is labeled for its band.
GMRS-only user? See the GMRS / MURS version. Fire, SAR or law enforcement? See the Public Safety version.
Specifications
- Gain: ~3.5 dBi (1/4 wave)
- Impedance: 50 Ω
- Electrical efficiency: ~95%
- Pattern: omnidirectional
- Connector: BNC male (clasp-style)
- Max power: 50 W
- Radiator: 1.6 mm NiTinol, stands straight in sub-zero temperatures
- Submersible
Adapter by radio
Same adapter for every band option on this listing, including the monoband.
| Radio | Adapter |
|---|---|
| Baofeng UV-5R, UV-5RM, BF-F8HP, UV-82, UV-17, DM-32 (and nearly all other Baofengs) | SMA F to BNC F |
| BTECH UV-PRO, GMRS-PRO, DMR-6X2 / 6X2 PRO, DA-7X2, GMRS-V2, MURS-V2, UV-5X3, BF-F8HP / BF-F8HP PRO, UV-82HP, UV-82C | SMA F to BNC F |
| Older BTECH: UV-5R / 5R+ / 5RE / 5RA / 5RC, UV-82 / 82X, GT-3 Mk II, GMRS-V1, MURS-V1, UV-F8+ | SMA F to BNC F |
| Quansheng UV-K5 / UV-K6 | SMA F to BNC F |
| Motorola APX series | SMA F to BNC F |
| BK / KNG (BKR5000) | SMA F to BNC F |
| Hytera HP782 | SMA M to BNC F |
| Yaesu FT-60R, FT-65R, VX-6R, FT-5DR, FT-3DR (and most other Yaesu handhelds) | SMA M to BNC F |
| Kenwood TH-D74 / TH-D75 | SMA M to BNC F |
| Older BK / BKR | SMA M to BNC F |
Radio not listed? SMA gender is set by the center pin, not the threads: a pin on the radio means the SMA F to BNC F, a hole means the SMA M to BNC F. Still unsure? Ask us.
FAQ
Which radios does it fit? Any radio with a BNC port, or SMA radios with an adapter: Baofeng, Yaesu, Quansheng, Motorola, Hytera and similar VHF/UHF handhelds.
Do I need an adapter? Yes, for about 99% of handhelds. SMA gender is set by the center pin, not the threads. If your radio's antenna port has a pin, use the SMA Female to BNC Female adapter (Baofeng and similar). If it has a hole, use the SMA Male to BNC Female adapter (Yaesu and similar).
Will it work for Meshtastic? No. See the Mesh antennas.
Can it be submerged? Yes, it's submersible for marine and foul weather use.
Watch: Antenna Overview and Adapter Selection
